Panasonic AG-DVX200 4K Camcorder
| Harga | Rp 1,00 |
 |
Specifications
Sensor : 1 x 4/3-type MOS
Effective Pixels
4K: 1335 MP
UHD (29.97p): 1289 MP
UHD (59.94p): 871 MP
FHC: 1549 MP
Resolution
4K
DCI: 4096 x 2160
UHD: 3840 x 2160
HD
1920 x 1080
Dynamic Range : 12 stops
Frame Rates
DCI 4K: 24p
UHD 4K: 60p / 50p / 30p / 25p / 24p
1920 x 1080: 60p / 50p / 30p / 25p / 24p
Shutter Speed
59.94 Hz
60i/60p mode: 1/60, 1/100 , 1/120, 1/180, 1/250, 1/350, 1/500 sec, 1/750 sec, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
30p mode: 1/30, 1/50 sec, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
24p mode: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
50 Hz
50i/50p mode: 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
25p mode: 1/25, 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000=, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000
Slow Shutter Speed
59.94 Hz
60i/60p mode: 1/2, 1/4, 1/8, 1/15, 1/30
30p mode: 1/2, 1/4, 1/8, 1/15 sec 24p mode: 1/2 , 1/3, 1/6, 1/12 sec
50 Hz
50i/50p mode: 1/2, 1/3, 1/6, 1/12, 1/25
25p mode: 1/2, 1/3, 1/6, 1/12 sec
Synchro Scan Shutter
59.94 Hz
60i/60p mode: 1/60.0 to 1/249.8 sec
30p mode: 1/30.0 to 1/249.8 sec
24p mode: 1/24.0 to 1/249.6 sec
50 Hz
50i/50p mode: 1/50.0 to 1/250.0 sec
25p mode: 1/25.0 to 1/250.0 sec
Shutter Opening Angle : 5.0 to 360o in 0.5 deg steps (displayed in shutter angle)
VFR Recording Frame Rate
59.94 Hz
60p mode: 2, 15, 30, 40, 55, 58, 60, 62, 65, 75, 90, and 120 (frames per second)
30p mode: 2, 15, 26, 28, 30, 32, 34, 45, 60, 75, 90, and 120 (frames per second)
24p mode: 2, 12, 18, 20, 22, 24, 26, 28, 30, 36, 48, 60, 72, 84, 96, and 120 (frames per second)
50 Hz
50p mode: 2, 12, 25, 33, 45, 48, 50, 52, 55, 62, 75, 100, and 120 (frames per second)
25p mode: 2, 12, 21, 23, 25, 27
Minimum Subject Illumination
High Sens mode: 0.2 lx (F2.8, gain 18 dB, [1/2S] manual slow shutter)
Memory Card Slot : 2 x SD (UHS speed class 3 compatible)
Recording Video Signal : 8 bit 4:2:0
Video Compression Format : MPEG-4 AVC/H.264 High Profile (MOV/MP4/AVCHD)
Inputs
Timecode: In / out
Audio: 2 x 3-pin XLR
Outputs
1 x 3G-SDI
1 x HDMI (supports HDMI 2.0)
Lens
Focal Length : 12.8 to 167mm
Zoom : 13 x optical zoom, 20x iZoom (in FHD Only)
35mm Equivalent
DCI 4K: 29.5 to 384.9mm
UHD 4K/30: 30.6 to 397.8mm
UHD 4K/60: 37.2 to 483.6
FHD: 28 to 364mm
ND Filters : 1/4, 1/16, 1/64
Filter Attachment 72 mm
General
Power : DC 7.2 V (battery), DC 12 V (AC adaptor)
Power Consumption : 21.7 W
Operating Temperature : 0 oC to 40 oC (32 oF to 104 oF)
Operating Humidity : 10 % to 80 % (no condensation)
Weight (body only, excluding lens hood, battery, and accessories) :2.7 kg (5.95 lb)
Dimensions (excluding protrusion and eye cup) :
181 mm(H) x 216 mm(W) x 374 mm (D)
(7-1/8 inches x 8-1/2 inches x 14-23/32 inches)
Effective Pixels
4K: 1335 MP
UHD (29.97p): 1289 MP
UHD (59.94p): 871 MP
FHC: 1549 MP
Resolution
4K
DCI: 4096 x 2160
UHD: 3840 x 2160
HD
1920 x 1080
Dynamic Range : 12 stops
Frame Rates
DCI 4K: 24p
UHD 4K: 60p / 50p / 30p / 25p / 24p
1920 x 1080: 60p / 50p / 30p / 25p / 24p
Shutter Speed
59.94 Hz
60i/60p mode: 1/60, 1/100 , 1/120, 1/180, 1/250, 1/350, 1/500 sec, 1/750 sec, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
30p mode: 1/30, 1/50 sec, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
24p mode: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
50 Hz
50i/50p mode: 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec
25p mode: 1/25, 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000=, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000
Slow Shutter Speed
59.94 Hz
60i/60p mode: 1/2, 1/4, 1/8, 1/15, 1/30
30p mode: 1/2, 1/4, 1/8, 1/15 sec 24p mode: 1/2 , 1/3, 1/6, 1/12 sec
50 Hz
50i/50p mode: 1/2, 1/3, 1/6, 1/12, 1/25
25p mode: 1/2, 1/3, 1/6, 1/12 sec
Synchro Scan Shutter
59.94 Hz
60i/60p mode: 1/60.0 to 1/249.8 sec
30p mode: 1/30.0 to 1/249.8 sec
24p mode: 1/24.0 to 1/249.6 sec
50 Hz
50i/50p mode: 1/50.0 to 1/250.0 sec
25p mode: 1/25.0 to 1/250.0 sec
Shutter Opening Angle : 5.0 to 360o in 0.5 deg steps (displayed in shutter angle)
VFR Recording Frame Rate
59.94 Hz
60p mode: 2, 15, 30, 40, 55, 58, 60, 62, 65, 75, 90, and 120 (frames per second)
30p mode: 2, 15, 26, 28, 30, 32, 34, 45, 60, 75, 90, and 120 (frames per second)
24p mode: 2, 12, 18, 20, 22, 24, 26, 28, 30, 36, 48, 60, 72, 84, 96, and 120 (frames per second)
50 Hz
50p mode: 2, 12, 25, 33, 45, 48, 50, 52, 55, 62, 75, 100, and 120 (frames per second)
25p mode: 2, 12, 21, 23, 25, 27
Minimum Subject Illumination
High Sens mode: 0.2 lx (F2.8, gain 18 dB, [1/2S] manual slow shutter)
Memory Card Slot : 2 x SD (UHS speed class 3 compatible)
Recording Video Signal : 8 bit 4:2:0
Video Compression Format : MPEG-4 AVC/H.264 High Profile (MOV/MP4/AVCHD)
Inputs
Timecode: In / out
Audio: 2 x 3-pin XLR
Outputs
1 x 3G-SDI
1 x HDMI (supports HDMI 2.0)
Lens
Focal Length : 12.8 to 167mm
Zoom : 13 x optical zoom, 20x iZoom (in FHD Only)
35mm Equivalent
DCI 4K: 29.5 to 384.9mm
UHD 4K/30: 30.6 to 397.8mm
UHD 4K/60: 37.2 to 483.6
FHD: 28 to 364mm
ND Filters : 1/4, 1/16, 1/64
Filter Attachment 72 mm
General
Power : DC 7.2 V (battery), DC 12 V (AC adaptor)
Power Consumption : 21.7 W
Operating Temperature : 0 oC to 40 oC (32 oF to 104 oF)
Operating Humidity : 10 % to 80 % (no condensation)
Weight (body only, excluding lens hood, battery, and accessories) :2.7 kg (5.95 lb)
Dimensions (excluding protrusion and eye cup) :
181 mm(H) x 216 mm(W) x 374 mm (D)
(7-1/8 inches x 8-1/2 inches x 14-23/32 inches)
In the Box
Battery (VW-VBD58)
Shoulder strap
Battery charger
Microphone holder
AC adaptor,
Screw for microphone holder (12 mm)
Power code x 2
CD-ROM
Eye cup
Lens hood
Input terminal cap
Panasonic AG-DVX200 manual
Shoulder strap
Battery charger
Microphone holder
AC adaptor,
Screw for microphone holder (12 mm)
Power code x 2
CD-ROM
Eye cup
Lens hood
Input terminal cap
Panasonic AG-DVX200 manual
